Shelter Types Gallery

Hardened aircraft shelters (HAS) are built in many forms, depending on the protection level, the site and the way they are operated. Rexsteel co.,ltd supplies the right steel liner for each form with the Wonder Arch Panel (Arch Liner) and the Steel Rolled Arch Liner.

※ The images below are illustrations of shelter types and do not represent specific completed projects.

Shelter Types

Earth-covered hardened aircraft shelter
Earth-covered HASIllustration
Covered-type hardened aircraft shelter
Covered-type HASIllustration
Covered revetment shelter with Wonder Arch Panel (Arch Liner)
Covered revetment — Wonder Arch Panel (Arch Liner)Illustration
3rd-generation hardened aircraft shelter - Wonder Arch Panel (Arch Liner)
3rd-Gen HAS — Wonder Arch Panel (Arch Liner)Illustration
Row of 3rd-generation hardened aircraft shelters - Wonder Arch Panel (Arch Liner)
3rd-Gen HAS rowIllustration
Multi-bay arch shelter - Steel Rolled Arch Liner
Multi-bay arch shelter — Steel Rolled Arch LinerIllustration
Canopy-type alert aircraft shelter - Steel Rolled Arch Liner
Canopy-type alert shelter — Steel Rolled Arch LinerIllustration
Canopy-type multi-bay shelter - Steel Rolled Arch Liner
Canopy-type multi-bay shelter — Steel Rolled Arch LinerIllustration

Protective Layers

Multi-layer protective concept of a hardened aircraft shelter
Multi-layer protection concept (1)Illustration
Protective layer concept in a hardened aircraft shelter section
Multi-layer protection concept (2)Illustration

Fabrication & Erection

Wonder Arch Panel (Arch Liner) assembly
Wonder Arch Panel (Arch Liner) assemblyIllustration
Wonder Arch Panel (Arch Liner) arch erection
Wonder Arch Panel (Arch Liner) arch erectionIllustration
Wonder Arch Panels after NET-certified electrodeposition coating at the Rexsteel Haman factory
Wonder Arch Panel after NET-certified electrodeposition coating — Haman factoryActual photo
NET electrodeposition-coated panels need no primer - topcoat only, reducing total painting cost
NET electrodeposition-coated panels — no primer needed, topcoat only, lower total painting costIllustration
